功用与介绍/Brief Introduction：

该线由直线方程式挤出机螺杆洗瓶真空吹干一身机、胶囊液包装产量线轧盖机二台电脑单机游戏构成的，分成清理、吹干高压蒸汽过滤除菌和包装产量线塑封三办公区，集体可联动机制产量，也可电脑单机游戏使用的。可成功完成淋水、超音波波清理、冲水、冲气、真空吹干高压蒸汽过滤除菌、冷却塔、包装产量线、理盖、戴盖、轧盖等工艺。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

基本特征/Characteristic：

按照超声心动图波的洗涤及雾水循环冲洗器、远红外室温杀菌、双头装罐与密封等技木。整线三级联动自行保持。实际操作简简单单方便简洁，构建了电气自动化混合式化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技巧基本参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
可用規格 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这之中正确运行36Kw)(including normal working 36 kw)
电脑净含量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
