的主要用途与简单介绍/Brief Introduction：

全自然液压泵式膏体酱装灌机都是我工厂改变领域市场具体需求开发建设的新商品。什么是服务器采用了SUS304不锈钢304液压泵式计量检验泵运行装灌，且集自然上盖、自然旋盖、建筑机电电器设备为一起，社会经济实惠，征地赔偿大小小，密切技术应用于药业、食材、农药杀菌剂、所有、化状品等领域的固态包装机，具有GMP标准符合要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优点/characteristic：

◆用于轴向柱塞泵式计量检验泵运行包装，适用性各样乳白色度透明液体，定位精更高；泵的空间结构用于快接式拆开平台，利于清理、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式测量泵火塞环所选布料布料材质据制造业及全自动的成分的有所不同进行硅塑胶，四氟乙稀或另一所选布料布料材质，特别环境进行瓷砖所选布料布料材质。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC有效控制软件系统，变频柜调节，自主化程度较高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，会自动记数功能键。Lack of bottle filling, automatic counting function◆装量校准以便于，可是次校准基本量值溯源检定泵的充填量，也可采取多个量值溯源检定泵通过微幅校准；使用简单便捷，校准如何快速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆装灌针头具有防渗漏部件，充填时潜进瓶底装灌，速度慢下降，可以防止小气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆服务器可应用其他要求的塑料瓶子，修正简约，可在多日间内完全。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆设备按GMP需求的设计。The machine designed according to the requirements of GMP

科技性能指标/technic parameter：

可用于瓶里产品规格Size of bottles	20-1000ml（依照符合要求订制）20-1000 - ml (according to your need）
可用于塑料瓶子内径Apply the bottle diameter	¢20-¢150mm
选用盖子型号规格Apply the lid specifications	¢20-¢70mm
加工力量 production capacity	四头罐装：1000-2500瓶/个钟头 Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/钟头 Eight head filling: 2500-4000 bottles per hour 12头灌装生产线：4000-6000瓶/H 12 head filling: 4000-6000 bottles per hour
装量误差度The load error	±1%
旋盖合格证率Screw cover percent of pass	≥99%
电源模块power supply	380V，50HZ
额定功率power	3.0KW
供气gas sources	0.4-0.75MPA
时间操控speed control	变频器调速器variable speed
